Delta DRL-24V480W1EN 90-264VAC TO 24VDC 20A 480W Power Supply

DRL-24V480W1EN 90-264VAC TO 24VDC 20A 480W Power Supply

Part number DRL-24V480W1EN
Delta
R3,336.32
No tax
Product Overview The DRL-24V480W1EN LYTE II Power Supply is a high-capacity DIN rail-mounted unit delivering a stable 24V DC output at 480W (20A). Designed for demanding industrial and commercial applications, this power supply offers exceptional efficiency, reliability, and a compact footprint
Share
Sign in to save lists
IN STOCK at EXTERNAL supplier.
If ordered before 10AM:
DELIVERED in 3-5 business days (main centres)
or 5-7 business days (regional areas or large/heavy items)

Trade account holders pay COD and can qualify for pricing below the online store.

Request a quote Open a trade account
Secure checkout Nationwide delivery Genuine parts 011 568 9948

Product Overview

The DRL-24V480W1EN LYTE II Power Supply is a high-capacity DIN rail-mounted unit delivering a stable 24V DC output at 480W (20A). Designed for demanding industrial and commercial applications, this power supply offers exceptional efficiency, reliability, and a compact footprint despite its higher power rating.

Engineered for continuous performance, it is ideal for automation systems, control panels, and high-load electrical environments requiring consistent and dependable DC power.

Key Features

  • 24V DC Output | 480W Power (20A)
  • Wide Input Range: 90–264VAC (1 Phase)
  • Slim DIN Rail Design – space-saving installation
  • High Efficiency (up to ±93%)
  • Built-in Constant Current Circuit – ideal for reactive loads
  • Wide Operating Temperature: -30°C to +70°C
  • LED Indicator for DC OK Status
  • Fanless Cooling (Convection)

Applications

  • Industrial automation systems
  • Control panels and switchboards
  • Building management systems
  • Security and access control
  • General electrical installations

Technical Specifications

  • Output Voltage: 24V DC
  • Output Current: 20A
  • Output Power: 480W
  • Input Voltage: 90–264VAC
  • Frequency: 47–63Hz
  • Efficiency: Up to ±93%
  • Mounting Type: DIN Rail (TS35)

Dimensions & Weight

  • Dimensions (H x W x D):
    123.6 x 56 x 116.8 mm
  • Weight:
    0.87 kg

Why Choose This Power Supply?

The LYTE II series is designed to deliver high power density and dependable performance in demanding environments. Ideal for electricians, panel builders, and contractors working on larger systems requiring higher current output.

✅ Secure Checkout with PayFast & Apple Pay
✅ Nationwide Delivery
✅ All Prices Include VAT

  • Brand
  • Reference
    DRL-24V480W1EN
  • In stock
    5 Items

  • Voltage
    24 V
  • Current Rating
    20 A
  • Wattage
    480 W
  • Poles
    1P
